Capacity
1TB Form Factor M.2 2280 NAND Flash 3D NAND Controller SM2508
Dimensions
(L x W x H) 80 x 22 x 4.5mm / 3.15 x 0.87 x 0.18inch (w/ heatsink) 80 x 22 x 3.2mm / 3.15 x 0.87 x 0.13inch (w/o heatsink)
Weight
12g / 0.42oz (w/ heatsink) 8g / 0.28oz (w/o heatsink)
Interface
PCIe Gen5 x4 Sequential Read Up to 14,000MB/s (PC/Laptop)*, up to 6,500MB/s (PS5)* Sequential Write Up to 13,000MB/s* 4KB Random Read IOPS 2,000K 4KB Random Write IOPS 1,650K Operating temperature 0°C – 70°C Storage temperature -40°C – 85°C Terabytes Written (TBW) 2,960TB** Shock resistance 1,500G/0.5ms MTBF 1,600,000 hours
