Description
ViewSonic VG1655 16 Inch Touch Screen Portable Monitor
Features:
- Easily extend your content from laptops and mobile devices
- One-cable solution for audiovisual and power signal transmission
- Flexible display setup – work at any angle
- Compact size, light weight, and highly portable
- Sturdy and durable design
The ViewSonic VG1655 is a portable 16” Full HD monitor perfect for overcoming one-screen limitations outside the office. Extend the screen from phones, tablets, or laptops for mobile work, one-on-one presentations, or leisure entertainment. The two universal USB Type C connectors provide a one-cable solution for audiovisual and power signal transmission. The adjustable wide stand and pivot-able display will support your working angles. With the anti-slip cover, metal case, and aluminum stand, reliability is embodied in the design.
Audiovisual Extension while Power Charging
Broadcast your built-in Type C mobile device’s multimedia onto a bigger screen and charge (up to 60W) over one cable while powering from an external power bank/outlet over the other USB Type C cable.
Portable Size for Work & Fun
Larger, 16” display than most common laptops and weighing less than 1 kg. It perfectly outfits your mobile workplace, and can be used for multimedia play when taking a break.
Supports Vertical Layout
Besides common horizontal content, you may setup a pivot screen for table-reviewing, programming, photo-editing, gaming, etc
Magnetic Cover and Mat
Avoid damage during carry, the detachable magnetic cover is easy to put on. Used as a mat, its anti-slip surface prevents the monitor from sliding away.
Robust One-piece Design
With the metal case and endurable hinge, the fold-able aluminum stand makes the whole monitor a one-piece design.
Specification:
| Model | VG1655 |
| Display | |
| Display Size | 16 |
| Viewable Area | 15.6 |
| Panel Type | IPS Technology |
| Resolution | 1920 x 1080 |
| Resolution Type | FHD (Full HD) |
| Static Contrast Ratio | 800:1 (typ) |
| Dynamic Contrast Ratio | 50M:1 |
| Light Sourc | LED |
| Brightness | 250 cd/m² (typ) |
| Colors | 16.2M |
| Color Space Support | 8 bit |
| Aspect Ratio | 16:9 |
| Response Time(Typical GTG) | 6.5ms |
| Response Time (GTG w/OD) | 6.551ms |
| Response Time (Typical Tr+Tf) | 30ms |
| Viewing Angles | 178º horizontal, 178º vertical, CR>5; 170º horizontal, 170º vertical, CR>10 |
| Backlight Life | 15000 Hrs (Min) |
| Curvature | Flat |
| Refresh Rate (Hz) | 60 |
| Blue Light Filter | Yes |
| Color Gamut | NTSC: 45% size (Typ) |
| sRGB | 64% size (Typ) |
| Pixel Size | 0.179 mm (H) x 0.179 mm (V) |
| Surface Treatment | Anti-Glare, Hard Coating (3H) |
| Compatibility | |
| PC Resolution (max) | 1920×1080 |
| Mac® Resolution (max) | 1920×1080 |
| PC Operating System | Windows 10/11 certified; macOS tested |
| Mac® Resolution (min) | 1920×1080 |
| Connector | |
| USB 3.2 Type C Up Stream; DisplayPort Alt mode | 2 (60W power charger) |
| 3.5mm Audio Out | 1 |
| Mini HDMI | 1 |
| Power in | USB Type C (with video & data) |
| Audio | |
| Internal Speakers | 0.8Watts x2 |
| Power | |
| Eco Mode (Conserve) | 5.1W |
| Eco Mode (optimized) | 6W |
| Consumption (typical) | 7W |
| Consumption (max) | 7.3W |
| Voltage | AC 100-240V |
| Stand-by | 0.5W |
| Power Supply | External Power Adaptor |
| Controls | |
| Physical Controls | Up, Right, Down, Left, Power |
| On Screen Display | Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
| Operating Conditions | |
| Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing) | 20% to 90% |
| Input Signal | |
| Frequency Horizontal | 15 ~ 82KHz |
| Frequency Vertical | 50 ~ 75Hz |
| Video Input | |
| Digital Sync | TMDS – mini HDMI (v1.4), Micro-Packet – Type C |
| Ergonomics | |
| Tilt (Forward/Back) | 20º / 60º |
| Weight (imperial) | |
| Net (lbs) | 1.8 |
| Net Without Stand (lbs) | 1.8 |
| Gross (lbs) | 4.8 |
| Weight (metric) | |
| Net (kg) | 0.82 |
| Net Without Stand (kg) | 0.82 |
| Gross (kg) | 2.2 |
| Dimensions (imperial) (wxhxd) | |
| Packaging (in.) | 17.3 x 11.3 x 3.5 |
| Physical (in.) | 14 x 8.8 x 0.6 |
| Physical Without Stand (in.) | 14 x 8.8 x 0.6 |
| Dimensions (metric) (wxhxd) | |
| Packaging (mm) | 440 x 288 x 89 |
| Physical (mm) | 355 x 223 x 16 |
| Physical Without Stand (mm) | 355 x 223 x 16 |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
