| General Feature |
|
| Application |
Client PCs, Game Consoles |
| Capacity |
2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Form Factor |
M.2 (2280) |
| Interface |
PCIe Gen 4.0 x4, NVMe 2.0 |
| Dimension |
80 x 22 x 2.3 mm |
| Weight |
Max 9.0g Weight |
| Storage Memory |
Samsung V-NAND 3-bit MLC |
| Controller |
Samsung in-house Controller |
| Cache Memory |
Samsung 1GB Low Power DDR4 SDRAM |
| Special Feature |
|
| TRIM Support |
Supported |
| S.M.A.R.T Support |
Supported |
| GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
| Encryption Support |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| WWN Support |
Not supported |
| Device Sleep Mode Support |
Yes |
| Performance |
|
| Sequential Read |
Up to 7,450 MB/s * Performance may vary based on system hardware & configuration |
| Sequential Write |
Up to 6,900 MB/s * Performance may vary based on system hardware & configuration |
| Ramdom Read (4KB, QD32) |
Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration |
| Ramdom Write (4KB, QD32) |
Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration |
| Ramdom Read (4KB, QD1) |
Up to 22,000 IOPS * Performance may vary based on system hardware & configuration |
| Ramdom Write (4KB, QD1) |
Up to 80,000 IOPS * Performance may vary based on system hardware & configuration |
| Environment |
|
| Average Power Consumption |
*Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
| Power Consumption (idle) |
Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration |
| Allowable Voltage |
3.3 V ± 5 % Allowable voltage |
| Reliability |
1.5 Million Hours Reliability (MTBF) |
| Operating Temperature |
0 – 70 ℃ Operating Temperature |
| Shock |
1,500 G & 0.5 ms (Half sine) |
| Warranty |
5-Year Limited Warranty or 1200 TBW Limited Warranty |
| Note** |
**Prices, Specifications & Features are subject to change without notice |
