Description
CyberPower UT1200E 1200VA Ups
Features:
- Line-interactive UPS Topology
- Automatic Voltage Regulation (AVR)
- Generator Compatible
- Simulated Sine Wave Output
- Overload Protection
- EMI and RFI Filtration
- LED Status Indicator
- Configurable Alarm
- Tower Form Factor
Designed for home, SOHO office and office applications, the UT Series adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output. The products are compatible with generators to extend power continuity. Other features include overload protection and configurable alarm to safeguard your devices.
Specifications:
| Model Name | UT1200E |
| General | |
| UPS Topology | Line-interactive |
| Input | |
| Generator Compatibility | Yes |
| Nominal Input Voltage (Vac) | 230 ± 10% |
| Input Voltage Range (Vac) | 140 ~ 300 |
| Input Frequency (Hz) | 50 ± 10, 60 ± 10 |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current (A) | 5.45 |
| Input Connector Type | IN |
| Output | |
| Capacity (VA) | 1200 |
| Capacity (Watts) | 720 |
| On Battery Waveform | Simulated Sine Wave |
| On Battery Voltage(s) (Vac) | 230 ± 10% |
| On Battery Frequency (Hz) | 50 ± 1%, 60 ± 1% |
| Automatic Voltage Regulation (AVR) | Double Boost, Single Buck |
| Outlet(s) – Total | 4 |
| Outlet Type | IN x 4 |
| Outlet(s) – Battery Backup | 4 |
| Battery | |
| Runtime at 60W (min) | 65 |
| Runtime at 90W (min) | 40 |
| Runtime at 200W (min) | 14 |
| Typical Recharge Time (Hours) | 8 |
| User-replaceable | No |
| Battery Type | Sealed Lead-acid |
| Replacement Battery Pack | RBP0165 |
| RBP Quantity (pcs) | 2 |
| Surge Protection & Filtering | |
| EMI/RFI Filtration | Yes |
| Management & Communications | |
| LED Indicators | Power On, Line Mode, Battery Mode, Battery Capacity, Low Battery |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Physical | |
| Form Factor | Tower |
| Physical Size – UPS Module | |
| Dimensions (WxHxD) (mm.) | 148 x 178 x 298 |
| Weight (kg.) | 7.6 |
| Environmental | |
| Operating Temperature (°C) | 0 ~ 40 |
| Operating Relative Humidity (Non-condensing) (%) |
0 ~ 90 |
| Online Thermal Dissipation (BTU/hr) | 52 |
| Certifications | |
| Certifications | BIS |
| RoHS | Yes |
| Warranty | 2 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
