Description
ASRock AMD Radeon RX 9060 XT Steel Legend OC 8GB GDDR6 Graphics Card
Clock: GPU / Memory
- Boost Clock*: Up to 3320 MHz / 20 Gbps
- Game Clock**: 2780 MHz / 20 Gbps
Key Specification
- AMD Radeon™ RX 9060 XT GPU
- 8GB GDDR6 on 128-Bit Memory Bus
- AMD RDNA™ 4 Architecture
- 32 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators)
- Microsoft® DirectX® 12 Ultimate
- PCI® Express 5.0 Support
- 1 x 8-pin Power Connector
- 2 x DisplayPort™ 2.1a, 1 x HDMI™ 2.1b
Key Features
- Polychrome SYNC
- Triple Fan Design
- Striped Ring Fan
- Stylish Metal Backplate
- Ultra-fit Heatpipe
- Air Deflecting Fin
- 0dB Silent Cooling
- Super Alloy Graphics Card
Â
| Specification | |
| Graphics Engine | AMD Radeon RX 9060 XT |
| Bus Standard | PCI® Express 5.0 x16 |
| DirectX | 12 Ultimate |
| OpenGL | Â 4.6 |
| Memory | 8GB GDDR6 |
| Engine Clock | Boost Clock*: Up to 3320 MHz
Game Clock**: 2780 MHz |
| Stream Processors | 2048 |
| Memory Clock | 20 Gbps |
| Memory Interface | 128-bit |
| Resolution | Digital Max Resolution: 7680Ă—4320 |
| Interface | 2x DisplayPort 2.1a
1x HDMI 2.1b |
| HDCP | Yes |
| Multi-view | 3 |
| Recommended PSU | 550W |
| Power Connector | 1x 8-pin |
| Accessories | 1 x Quick Installation Guide |
| Dimensions | 298 x 131 x 51 mm, 2.55-slot |
| Net Weight | 967 g |
| Warranty | 3 years |
| Note* | Price, feature and specifications are subject to change without notice. Images use for Representation Purpose Only. |
